BBC315 as Casting Bare Cylinder Head-Ximeng(chongqing)auto parts co.,ltd.

BBC315 as Casting Bare Cylinder Head Id：Cylinder Head BBC315 as Casting Bare Place of origin：CHINA

BBC315 as Casting Bare Cylinder Head

Online inquiry

Previous Next

Detailed content Specification parameters Product packaging

BBC315 as Casting Bare Cylinder Head

Material	A356 Aluminum	Recommended Components:	(.120" Thick)
Intake Port Volume	317cc	Intake Port Gasket	(.060" Thick)
Intake Port Dimension	2.450"H x 1.755"W x 13/32 Radius	Important: Do not port match your intake manifold to Fel-Pro gasket as it does not precisely fit the heads.
Intake Port Location	Stock	Exhaust Port Gasket	Head Gasket, Fel-Pro #1047 (Mark V and VI),Head Gasket,, Fel-Pro #1017-1 (Mark IV)
Exhaust Port Volume	135cc	Head Bolts, 7/16"-14 x 7/16"-14 ARP 235-7202	ARP 135-3703 (Mark IV), ARP 135-3707 (Mark V),ARP 235-4713
Exhaust Port Dimension	1.780"H x 2.025" W	Head Bolt Washers,	Manley
Intake Valve Diameter (in):	2.25 in.	Stud G irdle	7/16 Stud Mount Rocker Arms - 1.7 Ratio (For Optimized Geometry)
Exhaust Valve Diameter (in):	1.880 in.		1.7 Shaft Mount Rocker Arms T&D
Combustion Chamber Size	121cc	Suggested Manifold	Victor Jr,Super Victor
Valve Springs Pocket I.D.	1.735"	Spark Plug Starting Range	Pump Gas 3924 / Race Gas 3922
Maximum Valve Lift (in):	0.750 in.
Outside Diameter of Outer Spring (in):	1.625 in.	11/32" Intake Valve, 2.250" x5.500" O.A.L
Lock Style:	10 degree	11/32" Tulip Exhaust Valve, 1.880" x 5.450" O.A.L
Rocker Arm Nut Thread Size:	7/16-20 in.	Racing Spring #1224 1.625 O.D. Solid Roller, 275lbs on seat, .850 Maximum Lift, Max RPM 7400-7600
Valve Cover Mounting Style:	Perimeter bolt	10° Retainers 1.490" O.D x 1.180" I.D x .765" I.D
Intake Valve Angle:	24/4	10° 11/32" Valve Locks with lashcap recess
Exhaust Valve Angle:	15/4	ARP 7/16" Rocker Exhaust Studs
Valve Guide Material:	Manganese Bronze	ARP 7/16" Rocker Intake Studs
Intake Valve Seat Machine Style:	5-angle	3/8" Guide Plates
Valve Seat Material:	Mental powder	11/32" Viton Valve Seals
Oiling Style:	Through pushrod	Hardened Spring Cup 1.740" O.D / 1.650" I.D
		11/32" Intake Manganese Bronze Valve Guides .502" O.D x 2.10" O.A.L
		11/32" Exhaust Maganese Bronze Valve Guides .502" O.D x 2.25" O.A.L

We also supply the following models

Model Number	Intake Port Volume	Exhaust Port Volume	Combustion Chamber Size	Valve Angle
SBC Chevrolet 220cc CNC Bare Cylinder Head	220cc	80cc	65cc or 72cc	23°
SBC Chevrolet 210cc CNC Bare Cylinder Head	210cc	80cc	65cc or 72cc	23°
SBC Chevrolet 220cc As Casting Bare Cylinder Head	210cc	80cc	65cc or 72cc	23°
SBC Chevrolet 210cc As Casting Bare Cylinder Head	210cc	80cc	65cc or 72cc	23°
SBC Chevrolet 180cc As Casting Bare Cylinder Head	180cc	64cc	65cc or 72cc	23°
SBC Chevrolet 200cc as Casting Bare Cylinder Head
SBF220 as Casting Bare Cylinder Head	220cc	70cc	58cc	20°
SBC Chevrolet 180cc as Casting Bare Cylinder Head
BBM 245cc As Casting Bare Cylinder Head	245cc
BBM 210 As Casting Bare Cylinder Head	210cc			15°
SBF220 CNC Bare Cylinder Head	220cc	70cc	58cc	20°
SBF220 as Casting Bare Cylinder Head	220cc	70cc	58cc	20°
SBF205 CNC Bare Cylinder Head	203cc	70cc	58cc	20°
SBF185 CNC Bare Cylinder Head	185cc	70cc	58cc	20°
SBF185 as Casting Bare Cylinder Head	190cc	70cc	58cc	20°
SBF175 as Casting Bare Cylinder Head	175cc(177.4)	66cc(66.4)	60cc	20°
Ford Fe As Casting Bare Cylinder Head				13°
Chrysler 360 assembly each			63cc	18°
SBM As Casting Bare Cylinder Head				18°
BBC360 CNC Bare Cylinder Head	360cc	135cc	121cc	24°/4° Int, 15°/4° Exh
BBC335 CNC Bare Cylinder Head	335cc	135cc	121cc
BBC 335 As Casting Bare Cylinder Head	335cc	135cc	121cc
BBC 315 CNC Bare Cylinder Head	315cc	135cc	121cc
BBC 360 As Casting Bare Cylinder Head	360cc	135cc	121cc
BBC 290 as Casting Bare Cylinder Head	290cc	135cc	112cc
BBC315 as Casting Bare Cylinder Head	317cc	135cc	121cc
